Small Brass Mixer Tap(duchas)

Model:20OR5003400

A small brass mixer tap(duchas) is a sophisticated faucet designed to control both hot and cold water with a single lever handle, ensuring convenience and precision. Featuring a 90° rotation mechanism, it allows users to seamlessly adjust the water temperature to their preference. Typically installed using a deck-mounted setup, this small brass mixer tap(duchas) is connected through two 2 1/2” HI Technoflex flexible hoses, each 35 cm long, facilitating easy installation and adaptability.

The small brass mixer tap(duchas) is equipped with a durable 35mm ceramic cartridge, which provides smooth operation and longevity. Constructed from high-quality brass—a blend of copper and zinc alloy—it ensures robustness and resistance to corrosion. The single-hole installation simplifies the process and enhances the aesthetic appeal by minimizing clutter around the basin. Ideal for modern bathrooms, the basin mixer combines functionality with a sleek design, offering both style and efficient water management.

Get A Quote

PREV:Polished Brushed Brass Shower Faucet Set(duchas)
NEXT:Wall Mount Garden Faucet(duchas)

Product Description

OPERATION	Handle with 90° rotation that allows mixing the water temperature.
CONNECTION	By 2 1/2” HI Technoflex flexible hoses of 35 cm.
TYPE OF CLOSURE	35mm Ceramic Cartridge. Installation set by Fast Fix, 2 Technoflex flexible hoses.
MATERIAL	Brass (Copper and Zinc Alloy).
Hot & Cold Water	Yes

FUNCIONAMIENTO
Manilla con giro en 90° que permite mezclar la temperatura del agua.

CONEXIÓN
Por 2 flexibles Technoflex 1/2” HI de 35 cm.

TIPO DE CIERRE
Cartucho Cerámico 35mm.
Set de instalación por Fast Fix, 2 flexibles Technoflex.

MATERIAL
Latón (Aleación Cobre y Zinc).

Maintenance & Care<
Cartridge
Ceramic Cartridge
Lifetime: 10 Years
Cleaning and maintenance:
Clean the faucet and valve core regularly to prevent the accumulation of scale and impurities. You can use vinegar or special cleaning agents to clean.
Repair:
Leaky Faucet: Shut Off the Water — Remove the Handle — Remove the Handle — Remove the Cartridge or Stem — Install New Cartridge — Reattach Faucet Handle.
When replacing parts, choose high-quality accessories that match the specifications of the original accessories to ensure compatibility and durability.
Replace Washers and O-Rings: If you notice drips, it might be due to worn-out washers or O-rings. These are inexpensive and can be easily replaced.
Replace: The age of your faucet
Aerator
Clean or Replace:
1. Remove the aerator from your faucet,keeping the parts in the order,clean with a toothbrush
2. For hard water deposits, soak the components in vinegar.
3. Align the new bubbler with the threads and rotate it to ensure a tight fit. Do not over-tighten to avoid damaging the threads.
Handle Care
Avoid Excessive Force: Be gentle with the faucet handles. Forcing them can wear out the internal components.
Lubrication: Occasionally, you can apply a bit of plumber's grease to the handle mechanism to keep it operating smoothly.
Hose
Repair:
1. Leak on the male or female connectors, cut off the pipe end and replace the connector.
2. Leaking from either end of the hose, such as at the faucet or spray attachment, replacing the rubber washers in the female end of the hose and or spray attachment.
Replace:
Leak in the middle of the hose
Maintenance
Annual Inspection: Consider inspect your faucets annually to ensure everything is in good working order.
Specific Faucet Types
Single-Handle Faucets: Check the cartridge inside the faucet for wear and replace if necessary.
Double-Handle Faucets: Inspect the valve seats and seals regularly, and replace if worn out.
Touchless Faucets: Clean the sensor area regularly to ensure it functions properly. Replace batteries or power sources as needed.
Protecting Finish
Avoid Harsh Chemicals: Use gentle, non-abrasive cleaners to avoid damaging the finish.
Dry After Use: Wipe the faucet dry after each use to prevent water spots and corrosion.
Polish: Use a chrome polish or a product recommended by the manufacturer to maintain the finish’s shine.
----------------------------------------------------------------------------------------------------------------------------------------------------
